The micrometer is suitable for different applications and microscopes of different sizes. If customization is required, please contact customer service.
Model | Pattern | Description | Diameter |
NE38 |
| Eyepiece Reticle with 3 Squares 10mm, 7mm, 4mm. Area Ratio A:B is 1:3 and B:C is 1:2 | 16mm/19mm/20.4mm/21mm/23mm/24mm/24.5mm/25mm/26mm/27mm |
NE57 |
| Eyepiece Reticle with Miller Squares pattern, 7x7 mm large square. The ratio of large to small square is 9:1 | |
NE57C |
| Eyepiece Reticle with Miller Squares pattern, 8x8 mm large square with centered smaller square, ratio 10:1 |
